Bollard – Donatello
OPERATIONS & ELECTRICAL
Input voltage : 120-277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : No dimming
Beam Angle : 120°
DESCRIPTION
The DONATELLO bollard is an elegant solution for your outdoor area lighting needs. Its robust and strong materials allow it to withstand the harshest of elements without a scratch. The Donatello features an innovative optical system providing illumination to your space while keeping the beam shielded from the eye.
ORDERING CODE
| FIXTURE FAMILY | POWER & SIZE | CCT | CRI | HOUSING & FINISH |
|---|---|---|---|---|
|
AE-OD-DN25 (400 lumens) Outdoor products Donatello Bollard Fixture |
-C10-32-6 120-277Vac 10 watts: 400 lumens 32” height 6” diameter |
-3 3000K CCT |
-80 80 CRI |
-B-M Thermoset powder coat graphite black aluminumcast housing with marine corrosion resistant finish |
|
AE-OD-DN26 Outdoor products Donatello Bollard Fixture |
-C20-42-8 120-277Vac 20 watts: 1000 lumens 42” height 8” diameter |
-4 4000K CCT |
-Z-M Thermoset powder coat mineral bronze aluminumcast housing with marine corrosion resistant finish |
|
|
-W-M ERALUX nebula white thermoset cast housing with marine corrosion resistant finish* *Contact for leadtimes and availability |
||||
|
-C35-42-8 120-277Vac 35 watts 42” height 8” diameter |
-5 5000K CCT |
-S-M Aluminum (RAL9006) thermoset cast housing with marine corrosion resistant finish* *Contact for leadtimes and availability |
