Bollard – Leonardo
OPERATIONS & ELECTRICAL
Input voltage : 120-277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : No dimming
Lens : Glass lens ring
DESCRIPTION
The LEONARDO bollard is an elegant solution for your outdoor area lighting needs. Its robust and strong materials allow it to withstand the harshest of elements without a scratch. The Leonardo features an innovative optical system providing illumination to your space while keeping the beam shielded from the eye.
ORDERING CODE
| FIXTURE FAMILY | POWER & SIZE | CCT | CRI | HOUSING & FINISH |
|---|---|---|---|---|
|
AE-OD-LD35 Outdoor products Leonardo Bollard Fixture |
-C5-32-6 120-277Vac 5 watts: 168 lumens 32” height 6” diameter |
-3 3000K CCT |
-80 80 CRI |
-B-M Thermoset powder coat graphite black aluminumcast housing with marine corrosion resistant finish |
|
AE-OD-LD36 Outdoor products Leonardo Bollard Fixture |
-C15-42-8 120-277Vac 15 watts: 402 lumens 42” height 8” diameter |
-4 4000K CCT |
-Z-M Thermoset powder coat mineral bronze aluminumcast housing with marine corrosion resistant finish |
|
|
-W-M ERALUX nebula white thermoset cast housing with marine corrosion resistant finish* *Contact for leadtimes and availability |
||||
|
-5 5000K CCT |
-S-M Aluminum (RAL9006) thermoset cast housing with marine corrosion resistant finish* *Contact for leadtimes and availability |
