Eleganza – Cable Mount
Previous image
Next image
OPERATIONS & ELECTRICAL
Input voltage : 120-277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : Tri Mode Dimming ™(TRIAC, ELV & 0 10 V)
Lumens per Watt : 95 LPW at 90CRI
Beam angle : 15˚, 30˚, 40˚, 55˚
DESCRIPTION
The ELEGANZA Pendant series is a beautiful and elegant solution for open ceilings, and it has a distinctive design featuring machined aluminum body, attention to details including the installation process. The ELEGANZA also has an impressive LPW providing performance as well as elegance in the install environment. Finally, this product is a complete aluminum die cast offering an unparalleled sense of finesse, robustness and quality. It comes in various mounting options such as wall mount, surface mount, pendant and cord stem mount.
ORDERING CODE
| FIXTURE FAMILY | PRODUCT CODE | HEIGHT | MOUNTING METHOD | CABLE LENGTH | POWER | CCT | BEAM ANGLE | CRI | FINISH* |
|---|---|---|---|---|---|---|---|---|---|
|
AE-TL-EZ ERALUX Eleganza indoor cylindrical pendant fixture |
-40R |
12 12” fixture height |
-PC Cable mount fixture mounting method |
-03 3' cable |
-28 28 watts: 2,400 lumens at 90 CRI 3000K |
-C30 3000K CCT |
15 15° beam angle |
-P-T Premium 90 CRI |
-WH White powder coat finish |
|
-06 6' cable |
-C35 3500K CCT |
30 30° beam angle |
-BK Black powder coat finish |
||||||
|
-09 9' cable |
-C40 4000K CCT |
40 40° beam angle |
-SV Silver powder coat finish |
||||||
|
-12 12' cable |
55 55° beam angle |
