Eleganza – Wall Mount
OPERATIONS & ELECTRICAL
Input voltage : 120-277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : Tri Mode Dimming ™(TRIAC, ELV & 0 10 V)
Lumens per Watt : 95 LPW at 90CRI
Beam angle : 15˚, 30˚, 40˚, 55˚
DESCRIPTION
The ELEGANZA Cylinder Pendant series was created with a sleek design deliberately, so it could blend in with many different motifs and decors. It is a beautiful and elegant solution for open ceilings, and it has a distinctive design that just oozes quality. The ELEGANZA also has an impressive LPW of 85 LPW providing performance as well as elegance in the install environment. Finally, this product is a complete aluminum die cast offering an unparalleled sense of finesse, robustness and quality.
ORDERING CODE
| FIXTURE FAMILY | PRODUCT CODE | HEIGHT | MOUNTING METHOD | POWER | CCT | BEAM ANGLE | CRI | FINISH* |
|---|---|---|---|---|---|---|---|---|
|
AE-TL-EZ ERALUX Eleganza indoor cylindrical pendant fixture |
-40R |
12 12” fixture height |
-WM-00 Wall mount fixture mounting method |
-28 28 watts: 2,400 lumens at 90 CRI 3000K |
-C30 3000K CCT |
15 15° beam angle |
-P-T Premium 90 CRI |
-WH White powder coat finish |
|
-C35 3500K CCT |
30 30° beam angle |
-BK Black powder coat finish |
||||||
|
-C40 4000K CCT |
40 40° beam angle |
-SV Silver powder coat finish |
||||||
|
55 55° beam angle |
