GES

120V 50/60 Hz 20A max
cULus Listed

Desciption

ERALUX Track 1 is compatible with Juno single circuit Adapters. Track / Power Distribution System is suitable for retail, commercial and residential use. Ships with one T0009 (end cap) installed Extruded aluminum “I” beam. Thermoplastic insulator. Two #12 AWG solid copper conductors.

NOMINAL LGTH ACTUAL LENGTH ONE CIRCUIT
4-feet 44-inches GES-204-(color)
8-feet 92-inches GES-208-(color)
12-feet 140-inches GES-212-(color)

TRACK COMPONENTS

LIVE END FEED
GES 11 (-1,-2,-3)

CONDUIT END FEED
GES 13 (-1,-2,-3)

LINEAR COUPLER
GES 21 (-1,-2,-3)

LIVE MIDDLE FEED
GES 14 (-1,-2,-3)

FEEDABLE L-CONNECTOR
GES 34 (-1,-2,-3)

Feedable T-Connector
GES 40 (-1,-2,-3)

Feedable X-Connector
GES 38 (-1,-2,-3)

MONOPOINT
GES 70 (-1,-2,-3)

FLOATING FEED
GES 67 (-1,-2,-3)

CONDUIT CONT. KIT
GES 13&16 (-1,-2,-3)

T-BAR FEED KIT
GES 17 (-1,-2,-3)

CURRENT LIMITING DEVICE
GES 11CB (-2,-3)

OUTLET BOX COVER
GES 15 (-1,-2,-3)

DEAD ENDS
GES 41 (-1,-2,-3)

TRACK REINFORCEMENT PLATE
GEA21
