LSW
OPERATIONS & ELECTRICAL
Input voltage : 120~277V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : No dimming
Lumens per Watt : 110 LPW at 80 CRI White
Distribution : Lambertian
DESCRIPTION
The LSW series is the vandal-proof series from ERALUX with superior IK rating of IK10, a truly dustproof fixture with IP66 rating and an elegant design that can seamlessly be installed in your environment. The attention to detail in this product is unparalleled along with a versatility unseen in this type of product. The LSW series is available in various possible lengths, CCT along with a potential to link several products together with an ease of install that can positively impact install time.
ORDERING CODE
| FIXTURE FAMILY | VOLTAGE | LENGTH | POWER | CRI | CCT | CONNECT TYPE |
|---|---|---|---|---|---|---|
|
AE-SF-LSW ERALUX LSW linear fixture |
-UV 120-277Vac |
2FT 2 feet length |
030W 30 watts: 3300 lumens |
N 80 CRI |
40 4000K CCT |
TA Type A – Standalone fixture |
|
-4 4 feet length |
040W 40 watts: 4400 lumens |
|||||
|
060W 60 watts: 6600 lumens |
||||||
|
-6 6 feet length |
090W 90 watts: 9900 lumens |
50 5000K CCT |
TC Type C – Linkable fixture |
|||
|
-8 8 feet length |
120W 120 watts 13200 lumens |
