Odessan
OPERATIONS & ELECTRICAL
Input voltage : 100-277V, 200-480V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 130 LPW at 80CRI
Beam angle : 120˚
DESCRIPTION
Designed by Canadians for Canada, the ODESSAN series is uniquely designed for operations at 347V while providing the maximum possible performance in LPW. The lumens package ranges from 13,000 up to 26,000 lumens at 130 LPW. The ODESSAN series is available in both black and white finish enabling you to enhance your warehouses, grocery stores, gyms and other potential locations.
ORDERING CODE
| FIXTURE FAMILY | POWER | VOLTAGE | CCT | BEAM ANGLE | LED CODE | CONTROLS | CRI | FINISH |
|---|---|---|---|---|---|---|---|---|
|
AE-IL-ON ERALUX industrial fixtures Odessan Series round high bay |
100W 100 watts: 13,000 lumens |
-HS 277-480Vac input voltage range |
-35 3500K CCT |
120G- 120˚ beam angle |
-112 112 LED code |
-D 0-10V external dimming down to 10% |
80 Normal 80 CRI |
-BK Black finish |
|
150W 150 watts: 19,500 lumens |
-UC 120-277Vac input voltage range |
-40 4000K CCT |
-168 168 LED code |
-WH White finish |
||||
|
200W- 200 Watts: 26,000 lumens |
-50 5000K CCT |
-224 224 LED code |
