OPERATIONS & ELECTRICAL
Input voltage : 120-277V, 277-480V
Power factor : 0.95
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 135 LPW at 80CRI
Beam angle : 120˚
DESCRIPTION
The Saber series is an elegantly designed high bay LED luminaire that brings out the best of your space. The HB-01’s high efficacy of 150LPW and wide selection of power options allows you to enhance your project spaces, whether that be a factory, commercial gym, or showroom.
ORDERING CODE
FIXTURE FAMILY | POWER | VOLTAGE | CONTROLS | CCT | MOUNTING | FINISH |
---|---|---|---|---|---|---|
AE-IL-SB ERALUX SABER Series industrial fixtures round high bay |
-100W 100 watts: 13,500 lumens |
-UV 120-277Vac input voltage range |
-D 0-10V external dimming down to 10% |
-35 3500K CCT |
-HK Hook mount for suspension |
-BK Black powder coat finish |
-150W 150 watts: 20,250 lumens |
-40 4000K CCT |
|||||
-200W 200 Watts: 27,000 lumens |
-HV 277-480Vac input voltage |
-M Microwave motion sensor |
-50 5000K CCT |
-PM ¾” NPT pole mount adapter for pendant mount |
-WH White powder coat finish |
|
-240W 240 Watts: 32,400 lumens |
-UB U-bracket mount |
-CS Custom RAL finish |
