OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 88 LPW at 90CRI white, 75 LPW at 90CRI black
Distribution : Lambertian
DESCRIPTION
The SPINEL SLIM series is a revolutionary compact product with the ability to adjust lumen output and offers a variety of uplight and downlight options. It even offers the unique option of 100% uplight. Whether its pendant mount or wall mount, the installation process is simple and will result in an elegant lighting solution.
ORDERING CODE
FIXTURE FAMILY | GEN | VOLTAGE | SIZE | POWER | ACCENT | CRI | CCT | DIMMING | LENS | FINISH | BEAM |
---|---|---|---|---|---|---|---|---|---|---|---|
AE-SF-SPS ERALUX Spinel Slim linear architectur al fixture | -A First GEN | -CA 120- 347Vac input voltage range | -2 2 feet length | 30 20/30W* | -B No Accent | -P 90 CRI | -30 3000K CCT | 010 0-10V external dimming down to 10% | -PL Full length polycarbonate lens | -WH ERALUX Nebula White finish | [LEAVE
BLANK] 30% up light, 70% -4 downlight |
-4 4 feet length | 50 30/40/50W** | -35 3500K CCT | |||||||||
-6 6 feet length | 80 50/60/80W*** | -40 4000K CCT | -BK ERALUX Atomic Black finish | -100U 100% up light, 0% downlight | |||||||
-8 8 feet length | 100 60/80/100W**** | -50 5000K CCT | -SV Silver-RAL7044 | -60U40D 60% up light, 40% downlight |
ACCESSORIES
Part Number | Description (Ordered separately, field installed) | Picture |
---|---|---|
AE-SF-CANOPY-WH-5IN AE-SF-CANOPY-BK-5IN | Canopy Cover kit: 5” diameter - 2 pieces
White Canopy Cover kit: 5” diameter - 2 pieces Black | |
AE-SF-LINK-NR | Linkable Metal Accessory 1 piece Fixture wired for continuous mounting | |
AE-SF-G6-SMT-WH AE-SF-G6-SMT-BK | Surface mount kit – 1 piece – White Surface mount kit – 1 piece – Black | |
AE-SF-WMB-WH AE-SF-WMB-BK | Wall mount kit – 2 pieces White Wall mount kit – 2 pieces Black | |
AE-SF-PWRCORD-WH AE-SF-PWRCORD-BK | 8FT power cord – 120-277V - White 8FT power cord – 120-277V - Black | |
AE-SF-PWRCORD-WH-18FT AE-SF-PWRCORD-BK-18FT | 18FT power cord – 120-277V - White 18FT power cord – 120-277V - Black | |
AE-SF-PWRCORD-HV-WH AE-SF-PWRCORD-HV-BK | 8FT power cord – 120-347V - White 8FT power cord – 120-347V - Black | |
AE-SF-PWRCORD-HV-WH-18FT-B AE-SF-PWRCORD-HV-BK-18FT-B | 18FT power cord – 120-347V - White 18FT power cord – 120-347V - Black | |
AE-SF-A-SPS-A-CA-L-30-PXX-PL-WH AE-SF-A-SPS-A-CA-L-30-PXX-PL-BK | L-shape link-White L-shape link-Black | |
AE-SF-A-SPS-A-CA-T-40-PXX-PL-WH AE-SF-A-SPS-A-CA-T-40-PXX-PL-BK | T-shape link-White T-shape link-Black | |
AE-SF-A-SPS-A-CA-X-50-PXX-PL-WH AE-SF-A-SPS-A-CA-X-50-PXX-PL-BK | X-shape link-White X-shape link-Black | |
