Titan EVOLVE

OPERATIONS & ELECTRICAL

Input voltage : 120-277V, 347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 130 LPW at 80CRI
Beam angle :  120˚

DESCRIPTION

The TITAN Series linear highbay offers a robust design with a high lumen output. The Titan series is available in a range of size, power, and CCT options making it the linear high bay for your industrial lighting needs. The Titan EVOLVE has switchable lumens packages allowing you to change its power levels at the location site depending on your lighting needs. Its high lumen efficacy of 130 lumen per watt allow it to be an economical option by lowering your energy consumption.

ORDERING CODE

FIXTURE FAMILY VOLTAGE SIZE POWER CONTROLS CCT LENS
AE-IL-TTE
ERALUX Titan
EVOLVE industrial
fixtures rectangular
high bay
UV
120-277Vac
input voltage range
2FT
2 feet
lengtht
165
125/150/165 watts:
16250/19500/21450
lumens selectable
-D
0-10V external
dimming down to 10%
-35K
3500K CCT
-FR
Frosted lens
CA
120- 347Vac
input voltage
4FT
4 feet
lengtht
220
180/200/220W:
23400/26000/28600
lumens selectable
-40K
4000K CCT
300
250/300W: 32500/39000
lumens selectable
-MS
Motion Sensor
-50K
5000K CCT
