Versa Gimbal

OPERATIONS & ELECTRICAL

Input voltage :120Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming :Triac dimming 10%-100%
Lumens per Watt :~70 LPW
Beam angle : ~120 Degrees

DESCRIPTION

The VERSA Series LED offers the freedom of directing light to the right place every time. This downlight series offers the versatility of being adjustable in beam direction, comes standard with CCT switchable option. The VERSA operates at 120V AC with Triac dimming.

ORDERING CODE

FIXTURE FAMILY SHAPE & SIZE POWER CONTROLS CCT
AE-DL-VS-
ERALUX VERSA Series
recessed downlight
4-
4” Round
housing
09W-
9.5W: 700 lumens
Replaces 32W CFL
TRIAC-
Triac dimming
P27/30/35/40/50
2700K/3000K/3500K/4000K/5000K
selectable CCT
