Wallpack – Aspire-Dusk
OPERATIONS & ELECTRICAL
Input voltage :120-347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 130 LPW at 80CRI
DESCRIPTION
The ASPIRE DUSK is an extension from the high quality, durable, and elegant ASPIRE wall pack series. The 2200K warm color temperature helps reducing blue light exposure around residential buildings and allows minimum effect on circadian rhythm. Its robust structure allows it to be rated for both wet and dusty locations and is fully functional in a large temperature range. The ASPIRE DUSK comes in a variety of power (switchable power from 30 watt to 120 watt) and options, while providing a luminous efficacy of 130 LPW.
ORDERING CODE
| FIXTURE FAMILY | POWER | PERFORMANCE | INPUT VOLTAGE | CCT | FINISH |
|---|---|---|---|---|---|
|
AE-WP-AP- ERALUX Aspire Dusk Series outdoor wall pack light fixture |
120W- Power switchable: 120W/90W/60W/30W 15,600/11,700/7,800/3,900 lumens |
H- Premium light diffusion |
HV- 120-347Vac input voltage range |
2200K- 2200K CCT |
BZ Bronze powder |
|
BK Black Powder |
