Wallpack -Astellano Evolve
OPERATIONS & ELECTRICAL
Input voltage :120-277V, 120-347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 120 LPW at 80CRI
DESCRIPTION
The Astellano is the traditional wall packs enhanced with progressive led technologies, photocell, among others. The wall pack delivers up to 120 LPW in a variety of power and CCT options. It is heavy-duty aluminum die cast housing, is fully sealed to be dirt proof and proven to withstand the outdoor elements. The Astellano is the living proof where performance can be found in long standing traditional products.
ORDERING CODE
| FIXTURE FAMILY | POWER | CONTROLS | CCT | VOLTAGE | FINISH |
|---|---|---|---|---|---|
|
AE-WP-WP01- ERALUX Astellano GEN2 Series outdoor wall pack light fixture |
060 60 watts: 7200 lumens 40 watts: 4800 lumens 30 watts: 3600 lumens 20 watts: 2400 lumens |
D 0-10V external dimming down to 10% |
35 3500K CCT |
[BLANK] 120-277V |
-BK Black powder coat finish |
|
40 4000K CCT |
-BZ Bronze powder coat finish |
||||
|
120 120 watts: 14400 lumens 100 watts: 12000 lumens 90 watts: 10800 lumens 80 watts: 9600 lumens |
PD Photocell with Dimming |
50 5000K CCT |
-M 120-347V |
-WH* White powder coat finish * Contact manufacturer for leadtime |
|
|
-AL* Aluminum (RAL9006) powder coat finish * Contact manufacturer for leadtime |
