Wallpack – TZ series
OPERATIONS & ELECTRICAL
Input voltage :120-277V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : ~140 LPW at 70CRI and 5000K
DESCRIPTION
The TZ series differentiates itself from other wallpacks for its slim “dark sky friendly” look to save space, and the installation angle can be adjusted. With Type 3 optical lenses and IP wet location rated, its compact structure will provide a defining look to brighten up pathways and entrances in residential areas, as well as building facades.
ORDERING CODE
| FIXTURE FAMILY | POWER | CRI | CCT | VOLTAGE | FINISH | CONTROLS |
|---|---|---|---|---|---|---|
|
AE-WP-TZ ERALUX TZ series outdoor wedge wall pack |
||||||
|
-40 12/20/30/40 watts: Up to 5,600 lumens |
-70 70 CRI |
-SC1 3000K/4000K CCT selectable |
-UV 120 - 277 V |
-BZ Bronze Finish |
-B No dimming |
|
|
-70 21/35/53/70 watts: Up to 9,800 lumens |
-BK Black Finish |
-P Photocell motion sensor |
