Emergency Exit Light

EXITA CR-7111S

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 120/277Vac
Input Rating : 2w,150mA
Power Consumption : 2W
Run Time On Battery : 90min
Lamp Heads Power : 2.4W

Features & Benefits

Value Engineered Design
The housing is made of injection-molded thermoplastic ABS to provide safety against flame and fire.


Configurations
Universal field-selectable single/double-face, with fully illuminated 6” with universal red letter.


Multiple Mountings
It comes with three different mounting types. It can be installed on wall, on end, or on ceiling.


Battery Performance
The battery is made of 3.6V NiCad material and it is maintenance free. Its charging time is 24 hours, and it lasts for 90 minutes.


Two Lamp Heads
Each head contains 12PCS 0.2W to provide total 2.4W.


IP65 Protection
This exit sign is wet protected; thus, it is suitable for outdoor applications.


Description

The CR-7111SR has long life high intensity LEDs, it is encased in a fire-resistant thermoplastic ABS housing, while performing in damp locations. It designed for outdoor applications, and suitable for wet locations. It can be single or double face with red letters. And it comes with two lamp heads 1.2W each.

Downloads

Spec Sheet EXITA CR-7111S

Download

Install Instruction CR-7111S

Download

Product Configurator

Your Product Code :

Color Finish

Powder White Finish

Control

On/Off

Certifications

5 Year Warranty

RoHS

UL Recognized

IP65 Certified
