GUARDIANS
You may also like…
Additional Information
OPERATIONS & ELECTRICAL
Input Voltage : 120~277V
Power Factor : 0.9
Total Harmonic Distortion (THD) : <20%
Dimming : 0-10V external dimming & TRIAC dimming
Lumens per Watt : 110LPW at 90CRI
Distribution : 24˚, 38˚, 60˚
Features & Benefits
Premium Design and Material
Housing made from aluminum for increased rigidity and strength. Wet location rated and suitable for temperatures ranging from -20 to 45 degrees Celsius.
Multiple Beams
24, 38 and 60 Degrees
Various Reflector Options
Reflectors are available in specular, diffuse and charcoal black. They could fulfill all your needs to create a desirable lighting effect.
Protection
IP 54 Suitable for semi outdoor and wet areas
Description
The GUARDIANS series is the 4 , 5 and 6-inch commercial downlight family from ERALUX. This downlight features a spring mechanisms that makes installation a breeze. It is perfect for retrofit and for new constructions environment. The 4 inches can achieve up to 2500 lumens, 5 inches can achieve up to 3600 lumens and the 6 inches can achieve up to 4300 lumens at 90 CRI, 3000K. The GUARDIANS Series separates itself from competitor downlights by having selectable lumens, CCT switches, and magnetic reflector enabling high flexibility at the project location.
Downloads
Product Configurator
Your Product Code :
Dimensions
![](/wp-content/uploads/2024/01/Diameter.png)
4 inches
![](/wp-content/uploads/2024/01/Diameter.png)
5 inches
![](/wp-content/uploads/2024/01/Diameter.png)
6 inches
Output
1694lm
2190lm
2441lm
3016lm
3600lm
4056lm
Color and color temperature
![](/wp-content/uploads/2024/01/90-CRI.png)
90 CRI
![](/wp-content/uploads/2024/01/2700K.png)
2700K
![](/wp-content/uploads/2024/01/3000K.png)
3000K
![](/wp-content/uploads/2024/01/3500K.png)
3500K
![](/wp-content/uploads/2024/01/4000K.png)
4000K
![](/wp-content/uploads/2024/01/5000K.png)
5000K
Color Finish
![](/wp-content/uploads/2023/12/RAL-9003.png)
RAL 9003 Signal White
![](/wp-content/uploads/2023/12/RAL-9004.png)
RAL 9004 Signal Black
Optics
![](/wp-content/uploads/2023/12/24-Degrees.png)
24 Degrees
![](/wp-content/uploads/2023/12/38-Degrees.png)
38 Degrees
![](/wp-content/uploads/2023/11/60-Degrees.png)
60 Degrees
Control
![](/wp-content/uploads/2023/11/on-off.jpg)
On/Off
![](/wp-content/uploads/2024/01/0-10V.png)
0-10V Dimming
![](/wp-content/uploads/2024/01/TRIAC.png)
TRIAC
Accessories
![](/wp-content/uploads/2024/01/EMBB-2.png)
EMBB
Certifications
![](/wp-content/uploads/2023/11/5-years-warranty-Copy.jpg)
5 Year Warranty
![](/wp-content/uploads/2024/01/ETL-Canada-US.png)
ETL Canada & US
![](/wp-content/uploads/2024/01/RoHS-Certified.png)
RoHS Certified
