G5 T-Grid
OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 105 LPW at 80CRI
Distribution : Lambertian
DESCRIPTION
The G5 T-Grid series provide an unsurpassed flexibility for commercial offices. With a simple switch, the fixture can switch CCT and lumens. Long seamless rows are possible using custom lengths for starter, middle and ender. It is perfect for new buildings, upgrades and retrofit projects. This series has been redesigned to be easily mounted on most T grids ceilings.
ORDERING CODE
| FIXTURE FAMILY | VOLTAGE | LENGTH | WATTAGE | CCT | CONTROLS | FINISH | MOUNTING | TYPE |
AE-SF-G5 ERALUX G5 linear architectural fixture |
CA 120-347Vac input voltage |
2 2 feet fixture length |
20 20 watts: 2,100 lumens |
30/35/40 3000/3500/4000K selectable CCT |
-010 0-10V external dimming down to 10% |
WH-GB ERALUX Nebula White |
-R- Recessed mounting on T-grids |
A Stand alone |
|---|---|---|---|---|
|
4 4 feet fixture length |
40 40 watts: 4,200 lumens |
B Starter & Ender |
||
|
6 6 feet fixture length |
50 50 watts: 5,250 lumens |
30/40/50 3000/4000/5000K selectable CCT |
BK-GB ERALUX Atomic Black |
C Middle |
|
8 8 feet fixture length |
70 70 watts: 8,400 lumens |
