OPERATIONS & ELECTRICAL
Input voltage : 120,277, 347Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 125 LPW at 80CRI
Distribution : Lambertian
DESCRIPTION
The Mont Blanc series is an ideal solution for anyone looking to minimize waste, reduce install time and a revitalized ceiling. This product differentiates itself through its ease of install and access for maintenance. The Mont Blanc Evolve features a switchable CCT (3000K, 3500K, 4000k, OR 5000k) and switchable power levels (2 power level for the 2×2 and 3 power levels for the 2×4) for the fixture. This enables customization on site during final installation and provides an unparalleled level of flexibility.
ORDERING CODE
FIXTURE FAMILY | VOLTAGE | SIZE & POWER | DISTRIBUTION | CRI | CCT | CONTROL | FINISH |
---|---|---|---|---|---|---|---|
AE-RC-MB ERALUX Mont Blanc EVOLVE recessed commercial office volumetric troffer | UV 120-277Vac | 22 2 x 2 feet 24/36 Watts selectable: 3000/4500 lumens selectable | LB Lambertian distribution | N Normal 80 CRI | 30/35/40 3000/3500/4000K selectable CCT | 010 0-10V external dimming down to 10% | WH White |
MS1* Motion Sensor | |||||||
CA- 347Vac | 24 2 x 4 feet 36/42/50 Watts selectable: 4500/5250/6250 lumens selectable | 30/40/50 3000/4000/5000K selectable CCT | 000EM* Emergency battery backup | ||||
000B* EM+MS1 *Only for UV option |
