COMMERCIAL OFFICE FIXTURE

ALPS E3

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 120-277V / 120-347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 125 LPW at 80CRI
Beam Angle : Lambertian

Features & Benefits

Voltage Rating
Multiple input voltage ratings, 120-277Vac or 120-347Vac, perfect for both American and Canadian Markets.


Multiple Packages
Select from the standard 0-10V dimming model or add the additional 90-minute emergency battery back-up kit.


Thin Profile
Ultra-thin housing with polystyrene reflector enable the 2nd generation Alps fixture to be extremely lightweight while providing an elegant appearance.


Description

The ALPS series is a backlit panel product designed with optimum LED placement to ensure a uniformly lit diffuser. It features a switchable CCT, and power package enable an endless flexibility at the install site. The average 130 LPW performance also makes the ALPs an ideal replacement for any existing recessed commercial ceiling products.

Downloads

Install Instruction ALPS E3

Download

Spec Sheet ALPS E3

Download

Product Configurator

Your Product Code :

AE-RC-APB
POWER
SIZE
CONTROLS
INPUT VOLTAGE

Dimensions

2x2ft

2x4ft

1x4ft

Output

3125lm

3750lm

5000lm

6250lm

7500lm

Color and color temperature

80 CRI

3500K

4000K

5000K

CCT Switchable

Power Switchable

Color Finish

Nebula White Finish

Optics

Recessed Ceiling

Surface Mount

Control

On/Off

0-10V Dimming

Motion Sensor

Accessories

Gypsum Kit

Suspension Kit

Surface Mount Kit

Emergency Backup Battery

Certifications

5 Year Warranty

UL Certified

RoHs Certified

Dry Rated
