TRACK FIXTURE

HUBBLE

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 120V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : TRIAC DIMMING
Lumens per Watt : 85~91 LPW at 90CRI
Distribution : Variable from 20˚ to 55˚

Features & Benefits

MULTIPLE MOUNTING ADAPTERS
Choose from any of the popular track systems such as Juno, Halo, Lightolier, or Global.


VALUE ENGINEERED DESIGN
Aluminum die cast housing for superior thermal heat dissipation, strength, and rigidity. Integrated fin heat dissipation structure built into the fixture's housing provides long lasting LED and driver function.


PAINT FINISH:
Factory standard in black, white, and silver. Contact for custom paint finishes to enhance your fixture to suit your project space.


MULTIPLE OPTIONS
Customize your track head by selecting from a variety of CCT, CRI, and finish options.


FLEXIBILITY
Adjust the trackhead’s aperture to adjust the beam angle from 20 to 55 degree.


Description

The HUBBLE series feature the adjustable beam angle capability enabling field adjustment of the beam angle without any tools. The beam angle can be made to vary between a narrow flood, flood and a wide flood distribution. This product comes at a standard at 90 CRI, but also caters to lighting experts with a high-GAI (Gamut Area Index) option for an enhanced visual effect on products.

Downloads

Install Instruction HUBBLE

Download

Spec Sheet HUBBLE

Download

IES Files HUBBLE

Download

Product Configurator

Your Product Code :

AE-TL-HB
VOLTAGE
DISTRIBUTION
CRI
CCT
ADAPTER
FINISH

Dimensions

3.35inches

Output

2730lm

Color and color temperature

90 CRI

2700K

3000K

3500K

4000K

Color Finish

White Powder Coat Finish

Silver Powder Coat Finish

Black Powder Coat Finish

Optics

Variable Distribution From 20˚ to 55˚

Control

ON/OFF

TRIAC

Accessories

GES Adapter

Halo Adapter

Juno Adapter

Lightolier Adapter

Certifications

5 Year Warranty

ETL Canada & US

RoHs Certified
