Kepler
OPERATIONS & ELECTRICAL
Input voltage : 120 Vac
Power factor : >0.9
Total harmonic distortion (THD) : <30%
Dimming : Triac dimming
Lumens per Watt : 69-80 LPW at 90CRI
Distribution : Flood 25°, Wide Flood 35°, Very Wide Flood 55°
DESCRIPTION
The KEPLER fixture series was specifically designed as a sleek alternative to the traditional track light. It distinguishes itself with its slim and compact look, variety of optical options, and a series of accessories to adapt to every possible scenario. This product comes standard at 90 CRI. Available black, white and silver finishes, the Kepler is an easy addition to your next project.
ORDERING CODE
| FIXTURE FAMILY | DISTRIBUTION | CRI | CCT | ADAPTER | FINISH |
|---|---|---|---|---|---|
|
AE-TL-KP-12 ERALUX KEPLER Series track light 120vAC |
FL Flood light distribution 10 watts: 750 lumens at 90CRI 3000K CBCP: 2780 @ 90 CRI |
P Premium 90 CRI |
30 3000K CCT |
J1 Juno mounting system |
BK Black powder coat finish |
|
WF Wide Flood light distribution 10 watts: 750 lumens at 90CRI 3000K CBCP: 1590@ 90 CRI |
40 4000K CCT |
L1 Lightolier mounting system |
WH White powder coat finish |
||
|
VF Very Wide Flood light distribution 10 watts: 750 lumens at 90CRI 3000K CBCP: 840 @ 90 CRI |
H1 Halo mounting system |
SV Silver powder coat finish |
DIMMER
| Manufacturer | Type of Dimmer | Manufacturer Part Number |
|---|---|---|
| Lutron | Leading edge dimmers | SLV-600X |
| S2-LX | ||
| GL-600H | ||
| NFTU-5A | ||
| DVLV-600P | ||
| Trailing edge dimmers | NTELV-600-XX | |
| SELV-303P | ||
| MAELV-600-XX | ||
| DVELV-300P-XX | ||
| SEIV-300P-XX | ||
| Leviton | Leading edge dimmers | 6602-X |
| 6681-X | ||
| 6683-X | ||
| 6684-X | ||
| 700-X | ||
| 705-X | ||
| 6633 | ||
| 6674 | ||
| IPI06-1LZ | ||
| Trailing edge dimmers | ||
| IPE04-1LZ | ||
| VZE06-1LX | ||
| 6615-P0T | ||
| Cooper | Leading edge dimmers | 9530XXX |
| Lightolier | MP600X | |
| Philips | SR150LED120 | |
| Trailing edge dimmers | SR400RPC120 |
