TANGO E
You may also like…
Additional Information
OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 110~125 LPW at 90CRI
Distribution : 100˚ &105˚
Features & Benefits
Innovative Design
Housing made from aluminum forincreased rigidity and strength.
Wet location rated and suitable fortemperatures ranging from -20 to 40degrees Celsius.
Baffle reflector helps in reducing glare
Multiple Options
3 sizes 4”, 6”, and 8”
3 lumens selectable
5 CCT switchable from 2700K to 5000K.
Mountings Available
Durable stainless steel spring action housing clips for retrofit installations or purchase with the new construction frame kit for new constructions.
Accessories
New construction frame kit.8W Emergency back up battery.
Description
The TANGO E is a canless round recessed commercial downlight with an aluminum housing, matte-finish baffle reflector that helps in reducing glare, regressed lens and spring mechanisms for easy installation. It’s ideal for both retrofits and new construction in education, office, or commercial environments (frame kit required). Available in 4”,6” and 8”, it features selectable lumens and five CCT switches, offering great flexibility on-site. It will brighten your space by offering high lumen output around 110-125Lm/W.
Downloads
Product Configurator
Your Product Code :
Dimensions
4 inches
6 inches
8 inches
Output
1300/1500/1850lm
1350/1850/2300lm
2500/3250/4000lm
Color and color temperature
90 CRI
3000K
3500K
4000K
5000K
CCT Switchable
Power Switchable
Color Finish
Matte White
Optics
100 Degrees
Control
On/Off
0-10V Dimming
Accessories
Emergency Backup Battery
New Construction Frame Kit
Certifications
5 Year Warranty
ETL Certified
Energy Star Certified
RoHs Certified
Wet Rated
IC Rated
