DOWNLIGHT

TANGO X

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 86~93 LPW at 90CRI
Distribution : Lambertian

Features & Benefits

Energy Efficient Luminaire
Energy Star certified high-efficacy output of >86 lumens per watt at 90CRI.


Unparalleled Light Flexibility
Available in 3 sizes 4”, 6”, and 8”. Use the DIP switches on the top of the fixture's housing to switch between 3 lumen packages and 5 color temperature options from 2700K to 5000K.


Retrofit and New Construction
Durable stainless steel spring action housing clips for retrofit installations or purchase with the new construction frame kit for new constructions.


Premium Design and Construction
Housing made from aluminum for increased rigidity and strength. Wet location rated and suitable for temperatures ranging from -20 to 40 degrees Celsius.


Description

The TANGO X series is a commercial downlight family from ERALUX. This downlight features a spring mechanisms that makes installation a breeze. It is perfect for retrofit and for new constructions environment (junction box or frame kit required). The TANGO Series separates itself from competitor downlights by having selectable lumens, and five CCT switches, enabling high flexibility at the project location, it comes in three sizes; 4, 6, and 8 inches.

Downloads

Install Instruction TANGO X

Download

Spec Sheet TANGO X

Download

TANGO X IES Files

Download

Dimmer Compatibility List

Download

Product Configurator

Your Product Code :

AE-DL-TGX
SIZE
POWER
DIMMING
CRI
CCT
FINISH

Dimensions

4 inches

6 inches

8 inches

Output

650lm

1023lm

1395lm

930lm

1302lm

1670lm

1548lm

2064lm

2580lm

Color and color temperature



90 CRI



2700K



3000K



3500K



4000K



5000K



CCT Switchable



Power Switchable

Color Finish

RAL 9003 Signal White

Optics

95 Degrees

Control

On/Off

0-10V Dimming

Accessories

Emergency Backup Battery

New Construction Frame Kit

Certifications

5 Year Warranty

ETL Certified

Energy Star Certified

RoHs Certified

IC rated
