Artista 347 EVOLVE
OPERATIONS & ELECTRICAL
Input voltage : 120-347Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : 83 LPW at 90CRI
Beam angle : 90˚
DESCRIPTION
The Artista 347 EVOLVE Series LED downlight is the ideal recessed downlight for any retrofit or new construction project. Its voltage rating of 120-347V makes it highly suitable for both Canadian and American markets. The spring-action housing clips make the installation process a breeze in mere minutes for both the 6 and 8-inch sizes. The Artista 347 EVOLVE separates itself from competitor downlights by having selectable lumens and CCT switches enabling high flexibility at the project location. At just a flick of a switch, your power and colour projection can be varied, offering an unparalleled level of flexibility.
ORDERING CODE
| FIXTURE FAMILY | VOLTAGE | SHAPE & SIZE | POWER | CONTROLS | CCT |
|---|---|---|---|---|---|
| AE-DL-ATE- ERALUX Artista 347 EVOLVE recessed downlight | CA 120-347Vac 50/60Hz | 6- 6” Round housing | 12-17.5WT- 12/17.5W: 1000/1500lm Selectable Replaces 32W CFL | 010- 0-10V external dimming down to 10% | P30/35/40/50 3000/3500 4000K/5000K selectable CCT |
| 8- 8” Round housing | 18-24WT- 18/24W: 1500/2000lm Selectable Replaces 52W CFL | ||||
| 21-32WT- 21/32W: 2000/3000lm Selectable Replaces 84W CFL |
DIMMER
| Sample ID | Model |
|---|---|
| Cooper | DF10PC1 |
| Lutron Diva | DVSTV-WH |
| Levition | IP710-LFZ |
| Watt Stopper | ADF-120277 |
