ALPS E2
You may also like…
Additional Information
OPERATIONS & ELECTRICAL
Input voltage : 120-277V / 120-347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 125 LPW at 80CRI
Beam Angle : Lambertian
Features & Benefits
Voltage Rating
Multiple input voltage ratings, 120-277Vac or 120-347Vac, perfect for both American and Canadian Markets.
Multiple Packages
Select from the standard 0-10V dimming model or add the additional 90-minute emergency battery back-up kit.
Thin Profile
Ultra-thin housing with polystyrene reflector enable the 2nd generation Alps fixture to be extremely lightweight while providing an elegant appearance.
Description
The ALPS series is a backlit panel product designed with optimum LED placement to ensure a uniformly lit diffuser. It features a switchable CCT, and power package enable an endless flexibility at the install site. The average 130LPW performance also makes the ALPs an ideal replacement for any existing recessed commercial ceiling products.
Downloads
Product Configurator
Your Product Code :
Dimensions
![](/wp-content/uploads/2024/01/alps-2x2-top-view-3.png)
2x2ft
![](/wp-content/uploads/2024/01/2x4-top-view-1.png)
2x4ft
![](/wp-content/uploads/2024/01/1x4-top-view-e1704817756235.png)
1x4ft
Output
3125lm
3750lm
4375lm
5000lm
6250lm
Color and color temperature
![](/wp-content/uploads/2024/01/80-CRI.png)
80 CRI
![](/wp-content/uploads/2024/01/3500K.png)
3500K
![](/wp-content/uploads/2024/01/4000K.png)
4000K
![](/wp-content/uploads/2024/01/5000K.png)
5000K
![](/wp-content/uploads/2024/01/CCT-Switchable.png)
CCT Switchable
![](/wp-content/uploads/2024/01/Power-Switchable.png)
Power Switchable
Color Finish
![](/wp-content/uploads/2024/01/Nebula-White-Finish.png)
Nebula White Finish
Optics
![](/wp-content/uploads/2024/01/Recessed-Ceiling-2.png)
Recessed Ceiling
![](/wp-content/uploads/2024/01/Surface-Mount-3.png)
Surface Mount
Control
![](/wp-content/uploads/2024/01/On-Off.png)
On/Off
![](/wp-content/uploads/2024/01/0-10V.png)
0-10V Dimming
![](/wp-content/uploads/2024/01/Motion-Sensor-1.png)
Motion Sensor
Accessories
![](/wp-content/uploads/2024/01/Gypsum-Kit-2.png)
Gypsum Kit
![](/wp-content/uploads/2024/01/Hanging-Kit-1.png)
Suspension Kit
![](/wp-content/uploads/2024/01/Surface-mount-Kit-3.png)
Surface Mount Kit
![](/wp-content/uploads/2024/01/EMBB-2.png)
Emergency Backup Battery
Certifications
![](/wp-content/uploads/2023/11/5-years-warranty-Copy.jpg)
5 Year Warranty
![](/wp-content/uploads/2024/01/UL-Certified.png)
UL Certified
![](/wp-content/uploads/2024/01/RoHS-Certified.png)
RoHs Certified
![](https://eralux.com/wp-content/uploads/2024/01/dlc_premium-2-232x300.png)
DLC Premium
![](/wp-content/uploads/2024/01/Dry-Rated.png)
Dry Rated
