Signalisation lumineuse

GECO MFW1I0D2

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage: 24VDC
Power factor: 0.9
Total harmonic distortion (THD): <20%
Lumens per watt: 170LPW at 80CRI
Distribution: 170˚

Features & Benefits

Flexibility
Easily installed as multiple fixture that can be integrated together to form the required design, and providing 65000 CCT.


Different Mounting Method
They can either be installed using tape, or using screw for more rigidity.


Protection
These fixtures are versatile, they can work properly in any environment, since they are IP65 rated.


Description

The MFW1IOD2 from ERALUX is a compact and low-profile LED SIGNAGE LIGHT with a 170-degree beam angle. This enables these modules to be suitable for big channel letters of over 2.4-inch depth. These also have great heat dissipation to ensure long life expectancy. Comes in 20 pcs/string.

Downloads

Spec Sheet GECO MFW1I0D2

Download

Install Instruction GECO MFW1I0D2

Download

Product Configurator

Your Product Code :

MFW1I0D2
CCT

Output

204lm

Color and color temperature

80CRI

4000K

6500K

Optics

170 Degrees

Control

On/Off

Certifications

5 Year Warranty

RoHS

UL Recognized

IP65
