DOWNLIGHT

DISCO

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input Voltage : 120~277V
Power Factor : 0.9
Total Harmonic Distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 80-85 LPW at 90CRI
Distribution : 120º Beam Angle

Features & Benefits

Operations
Operates at 120 to 277V and can have 0-10v Dimming as well.


CCT Switchable
2700/3000/3500/4000/5000K CCT options in a single fixture.


Elegant White Finish
Uniformed nebula white finish provides a simple and elegant appearance making any indoor project superior.


Premium Design and Materials
Premium aluminum housing and acrylic lens. Robust ,high performing and yet refined finish.


Performance
1800 Lumens AT 21W AND 2000 Lumens at 25W both with a 90 CRI.


Description

The DISCO Series is the ideal solution for residences with a light source that provides a seamless transitions to various spaces. It comes in two different wattage and size options as in the 21W for 12 inch and 25W for 15 inch. This fixture also offers various CCT options of 2700K, 3000K, 3500K, 4000K and 5000K CCT that can be set in the field.

Downloads

Install Instruction DISCO

Download

Spec Sheet DISCO

Download

DISCO IES Files

Download

Product Configurator

Your Product Code :

AE-DL-DS
SHAPE & SIZE
INPUT VOLTAGE
CRI

Dimensions

5 inches

7 inches

9 inches

12 inches

15 inches

Output

950lm

1200lm

1400lm

1800lm

2000lm

Color and color temperature



90 CRI



2700K



3000K



3500K



4000K



5000K



CCT Switchable

Color Finish

RAL 9003 Signal White

Optics

120 Degrees

Control

On/Off

0-10V Dimming

Certifications

5 Year Warranty

UL Certified

Energy Star Certified

RoHS Certified

Wet Rated
