Infinita EVOLVE 4″
OPERATIONS & ELECTRICAL
Input voltage : 120Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 83 LPW at 80CRI
Beam angle : 90˚
DESCRIPTION
The Infinita EVOLVE Series LED downlight is the ideal solution for high end finish to the ceiling space. Driven to provide ultimate customization on site, the Infinita offers possibilities beyond the normal downlight in terms of flexible lumens output and flexible CCT adjustments. The Infinita comes with two possible reflector finish enable further customizations.
ORDERING CODE
| FIXTURE FAMILY | SHAPE & SIZE | POWER | CONTROL | CRI CCT | REFLECTOR FINISH |
|---|---|---|---|---|---|
|
AE-DL-IF- ERALUX Infinita EVOLVE recessed downlight |
04- 4” Round housing |
11W- 8/10/11 watt: 650/750/850 lumen – White reflector 500/600/700 lumen – Matt reflector |
010- 0-10V external dimming down to 10% |
P30/50 90 CRI 3000/3500 4000K/5000K |
-WH White smooth cone reflector with white flange |
|
-SD- Semi Diffused smooth cone reflector with white flange |
DIMMER
| Sample ID | Model |
|---|---|
| Cooper | DF10PC1 |
| Lutron Diva | DVSTV-WH |
| Levition | IP710-LFZ |
| Watt Stopper | ADF-120277 |
