Jobber
OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : ≥130 LPW at 80CRI
Distribution : Lambertian
DESCRIPTION
The JOBBER series is an economical yet discrete replacement for linear fixtures. They are available in 4- and 8-feet lengths and are designed to meet installation needs for surface mounting requirements. Furthermore, this luminaire offers performance above 130 LPW while showing great versatility in operating voltage from 120 to 347V. The luminous part is integrated and fastened to the fixture body by snap-locks which makes it easy to open fixtures. Field-adjustable light output and CCT options.
ORDERING CODE
| FIXTURE FAMILY | INPUT VOLTAGE | LENGTH | POWER | CCT |
|---|---|---|---|---|
|
AE-SF-JB ERALUX Jobber linear strip fixture |
CA- 120-347Vac |
04 4FT length 47.3’’ |
45/38/34 45 watts: ~5895 lumens 38 watts: ~4,978 lumens 34 watts: ~4,454 lumens |
-835-50 80 CRI CCT Switchable: 3500K/4000K/5000K |
|
08 8FT length 94.2’’ |
90/75/65 90 watts: ~11,790 lumens 75 watts: ~9,825 lumens 65 watts: ~8,515 lumens |
