Emergency Exit Light

EXITA-Z1102U

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 3.6~24Vdc
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Input Rating : 3.6V:550-620mA/ 12V:290-330mA/ 24V:160-200mA
Power Consumption : 3.6V/H:1.8-2.2W/ 12V/H:3.6-4.2W/ 24V/H:3.6-4.4W

Features & Benefits

Montage multiple
It comes with two different mounting types. It can be installed on wall, or on ceiling.


CCT options
6000K-6500K. Suitable for Damp Conditions


Value Engineered Design
The housing is made of injection-molded thermoplastic ABS to provide safety against flame and fire.


Adjustable Lamp Head
Each lamp head is fully adjustable they can rotate as shown on the image.


Description

Encased in thermoplastic ABS housing, the EXITA-Z1102U is a double LED remote head built to handle tough emergency situations. Capable of performing in damp conditions. Equipped with high impact thermoplastic, with an ultra bright SMD LED (2W). The adjustable swivels lock the head in flexible positions. Able to surface or wall mount. EXITA-Z1102U is a great choice for functionality and flexibility in emergency situations.

Downloads

Install Instruction EXITA-Z1102U

Download

Spec Sheet EXITA-Z1102U

Download

Product Configurator

Your Product Code :

Color and color temperature

6000K

6500K

Color Finish

Powder Coated White Finish

Control

On/Off

Certifications

5 Year Warranty

RoHS

UL Certified
