Outdoor Fixture

THALASSA ET6020

You may also like…

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 100~277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V (with DMG option)
Lumens per watt : 70 LPW at 80CRI
Distribution : for 24W: 10Ëš, 25Ëš, 38Ëš, 45Ëš, 60Ëš, & for 40W: 8Ëš, 18Ëš, 36Ëš, 62Ëš (Beam Angle)

Features & Benefits

PREMIUM MATERIALS AND DESIGN
Constructed from aluminum die-cast enhancing thermal heat dissipation while providing excellent figure strength.


MULTIPLE BEAM ANGLES
Customize your fixture with a unique set of beam angles in the uplight or downlight orientation with the option to having a 20-degree tilt towards the wall.


MULTIPLE FINISH OPTIONS
Select from black, white, or silver powder coat anti-cracking finishes to accent your project space.


CRI
80 CRI provides greater rendering allowing for a more natural light look.


Description

The Thalassa outdoor surface mounted cylindrical LED fixture was created  with a sleek design deliberately, so it could blend in with many different outdoor building styles. The Thalassa also has an impressive efficacy of 70 LPW providing performance as well as elegance in the install environment. Finally, this product is a complete aluminum die cast offering an unparalleled sense of finesse, fixture strength and quality.

Downloads

Spec Sheet THALASSA ET6020

Download

IES Files - THALASSA ET6020

Download

Product Configurator

Your Product Code :

ET6020
POWER
CCT
BEAM ANGLE
CRI
FINISH
CONTROLS

Dimensions

Front View

Top View

Output

1680lm

2800lm

Color and color temperature

80 CRI

3000K

4000K

5000K

6000K

Color Finish

White Powder Coat Finish

Black Powder Coat Finish

Silver Powder Coat finish

Optics

8 Degree

10 Degree

18 Degree

25 Degree

36 Degree

38 Degree

45 Degree

60 Degree

62 Degree

Control

On/Off

0-10V Dimming

Certifications

5 Year Warranty

ETL Certified

RoHs Certified

IP65 Rated
