Controls

DETECTA

Additional Information

OPERATIONS & ELECTRICAL
Input voltage : 120~277Vac
Rated Load : At 120Vac: 800W, & at 277Vac; 1200W
Detection Range : 3~10 METERS / 118~393 FT RADII
Standby Power : 0.9W
Time Setting : 10sec~30min
Light Control : 10~2,000 Lux

Features & Benefits

Mounting Method
It is installed on the ceiling.


Dual Technology
Combines the passive infrared sensor with the microphonic sensor. it can be controlled by motion as well as by light.


Range Coverage
it can cover up to 10 meters or 393 feet radius.


Light Detection
In addition to motion sensor it can be controlled by light in a range 10 to 2000 LUX


Description

The DETECTA Series is a dual technology sensor that combines passive infrared/PIR sensor and microphonics in one. The combination of these technologies enables the sensor to “see” and “hear” occupancy and triggers accordingly. This provides a level of control that avoid the inconvenience of having only PIR motion sensor that turns off light unnecessarily.

Downloads

Install Instruction Detecta

Download

Spec Sheet Detecta

Download

Product Configurator

Your Product Code :

Dimensions

Accessories

RC102 Remote Control

Certifications

5 Year Warranty

RoHS

ETL Certified
