Thalassa ET6123

OPERATIONS & ELECTRICAL

Input voltage :100-277Vac
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V external dimming down to 10%
Lumens per Watt : ~75 LPW at 80CRI

DESCRIPTION

The Thalassa outdoor wall-mounted square LED fixture was created with a sleek design deliberately, so it could blend in with many different outdoor building styles. The Thalassa also has an impressive efficacy of 75 LPW providing performance as well as elegance in the install environment. Finally, this product is a complete aluminum die-cast offering an unparalleled sense of finesse, fixture strength and quality.

ORDERING CODE

FIXTURE FAMILY POWER CCT BEAM ANGLE CRI FINISH CONTROLS
ET6123
ERALUX Thalassa
ET6123 outdoor
wall mounted
square sconce fixture
-C30x2
2x30 watts: 4800 lumens
-3
3000K CCT
-15
15˚ beam angle
-80
80 CRI
-B
Black powder
coat finish
-SDMG
Up and down separate
0-10V external dimming down
to 10%
-4
4000K CCT
-20
20˚ beam angle
-W
White powder
coat finish
-5
5000K CCT
-30
30˚ beam angle
-S
Silver (RAL9006)
powder coat finish
-60
60˚ beam angle
-G
Gray (RAL7012)
powder coat finish
-1560
Up: 15˚ beam angle
Down: 60˚ beam angle
-Z
Mineral bronze
powder coat finish
